Product Description
1. Product Features:
Air-proof, Water-proof, Sound Insulation, Thermal Insulation, Anti-aging
Good combustion-retarding performance, Easy maintenance, Environmental protection.
2. Aluminum Profile:
1) Thickness
1.4-2.0mm or as client's demand.
2) Material:
6063T4, 6063T5, 6063T6, 6061T4, 6061T5, 6061T6 etc.
3) Surface Treatment
Anodized, Electrophoretic, Powder Coated, PVDF, Wood Finished.
4) Series
40 Series, 50 Series, 55 Series, 60 Series, 70 Series, 80 Series, 90 Series, 100 Series, 110 Series etc.
3. Glass:
1) Thickness
5mm, 6mm, 8mm
5mm/6mm+6A/9A/12A+5mm/6mm
5mm/6mm+0.38/0.76/1.52mm+5mm/6mm
2) Material
Plate Glass, Tempered/Enforced Glass, Low-E Glass
3) Surface Treatment
Filmed, Reflective, Clear
4) Classification
Laminated, Insulation, Sigle
4. Hardware system:
Our standard hardware is in good quality, Chinese Brand or German Brand(ROTO, AUBI, GU). Customers' stipulated brand is available.
5. Seal system:
Ternary ethylene-propylene rubber sealing strip, black color, good quality.
6. Dimensions:
As per customers' sizes.
7. Mosquito meshes (screens):
Metal and nylon material net are available.
8. Performance parameters:
1) Sound Insulation
2) Water Resistance
3) Wind Pressure Resistance
4) Air Permeation Resistance
9. Packing:
Foam Paper+carton, pearl cotton+carton, wooden pallet etc
10. Drawing:
Our R&D team can make the windows and doors according to the Clients Demand or Drawing.
Any questions you have, pls don't hesitate to contact me!
| hot sales hurricane impact windows | |
| Size | customized |
| Profile | Aluminum Alloy |
| Profile thickness | 1.2mm or 1.4mm |
| Glass | single, double or triple glass |
| Color Option | white, dark grey, light grey, black, wooden grain or silver, etc. |
| Glass Option | Tempered, Clear, Low-e, tinted, frosted, laminated glass, and so on. |
| Hardware | China famous brand or German brand |
| Finish | 1. Powder coating 2.PVDF 3.Electrophoresis 4.Anodize |
| Sealant | PVC, EPDM |
| Flyscreen | Available |
| Measurement | Customized products according to clients |
| Performace | Corrosion-resistant, durable,non-deformable,energy-saving and ECO-friendly. |
Products photos:
heavy duty slide door,folding door,fixed glass,double hung slide window,single hung slide window,folding up window,horizontal
folding window,ventical folding window
| Product Name: | AS2047 Australia Standard Aluminum Awning Metal Window with Winder Chain Lock Mosquito Net Awning/Casement/Sliding/Folding Window |
| Aluminum Alloy+Glass | |
| Dimension: | Can be Customized |
| Window and Door Open Type: | (1)Casement window & door (2)Sliding window & door |
| (3)Folding window & door (4) Awning window | |
| (5)Arched window & door (6) Tilt & Sliding window & door | |
| (7)Tilt & Turn window & door, etc. | |
| Open Type: | Awning |
| Feature: | Waterproof/ sunscreen/ soundproof / rust-proof/ firm |
| Aluminium Profile: | Top-grade thermal break aluminum profile |
| Surface Treatment: | Powder Coated,Anodizing,Electrophoresis,Heat transfer for wood grain,PVDF coating |
| Aluminium Colors: | Sliver,Wood,Gold,Balck,White,Coffee,Gray,Any Color |
| Aluminium Thickness: | 1.2mm,1.4mm,1.8mm,2.0mm,Customize |
| Glass Type: | Single glass,Double glass,Tempered glass,insulating glass,frosted glass,reflective glass,laminated glass,low-E glass,radiation-shielding glass |
| Single Glass: 5mm,6mm,8mm,10mm,12mm | |
| Double Glass: 5mm+12A+5mm/5mm+14A+5mm/5mm+15A+5mm/5mm+18A+5mm/5mm+27A+5mm (Glass can be made 5mm/6mm/8mm/10mm/12mm) | |
| Triple Glass: 5mm+12A+5mm+12A+5mm(Glass can be made 5mm/6mm/8mm/10mm/12mm) etc. | |
| Glass Color: | Green/Silver/Gray/Tea/Mirror/Blue/Gold Coating etc. |
| Hardware: | HOPPE, ROTO,OEM,Chinese Brand |
| Package: | Protection foam+heat contracted plastic film/carton/wooden packing/Metal pallet or Depending on clients' special requirements |
| Delivery Time: | 15 working days after getting the deposit and drawing confirmation. |
Aluminum Awing Window.
▪The awing window has a large opening area and good ventilation▪Has good air tightness, excellent sound insulation and heat preservation
▪Easy maintainance
▪Suitable for bedroom, study room, bathroom, balcony, etc.
1.Material: Aerospace-grade 6063T6 primary aluminum with the great properties of sturdy construction,toughness and oxidation resistance and not easy to deform.
2.Technique: Pin-glue-injection technique,the third generation corner technique,is far more safer and stronger than first generation and the second generation technique.
3.Glass: Adopt the not-fully tempered glass forged by the unique temperature and verified by
3C certification.And we will use various glasses which have the well properties of sound,water
and heat insulation and airtightness and so on to meet various requirements. And we use
Technoform heating strip and other materials of domestic and overseas famous brand to provide
a excellent doors and windows performance.
4.Hardware: Imported hardware brand of well durability,including:HOPPE,CMECH. The thermal
break doors and windows use the PA66GF25 thermal break strip to ensure its remarkable heating
insulation performance.
| 1 | Item name | Aluminium Casement window with AS2208 standard |
| 2 | Aluminium profile | Standard/energy efficient aluminium profile with 1.4mm thickness. |
| 3 | Profile surface treatment | powder coating(with 70um thickness) Anodized(with 15um thickness) Electrophoresis(with 25um thickness) PVDF(with 40um thickness) |
| 4 | Glazed(AS2208) | A: single glazed like 5mm or 6 mm glass B: double glazed like 5+6/9/12+5mm. C: Triple glazed like 5+9+5+9+5mm D: Laminated glazed like 5+0.38/0.76/1.52+5mm E: Low-e glazed/tinted glazed/frosted/obscure glazed F: Can be with colonial/decorative bars G: All the glass we choose are Safety/tempered/toughed glazed |
| 5 | Glazed seal | Rubber (EPDM) or silicone sealant. |
| 6 | Hardware | German brand Roto/AUBI or made in china |
| 7 | Screen fly net | Nylon/Fiber glass/metal material |
| 8 | Dimensions | According to your design |
| 9 | Window color | Any color is available |
| 10 | Packing | Cardboard and iron pallet |
| 11 | Delivery time | 6-8 week |
| 12 | Performance Parameters | 1. Soud insulation: 33dB/500HZ 2. Wind pressure resistance: 4.0kPa 3. Air permeation resistance: 0.5m² /(h. m. ) 4. Water resistance: 500Pa 5. U-Value< 2.0w/m2. k |
Packing&shipping:
1.Protective tape protects products around ;
2.Use corner protection to protect products coner;
3.Keep windows or doors fixed on Wood case;
4.Tie up windows or doors with woodblock;
5.PE films to keep away from seawater;
6.Tie up whole wood case with Iron straps.
Our packages will ensure the windows and doors arrive at project Jobsite in good conditions.
Workshop&Showroom:
Our Services
| Before order | Free technique consulting, design windows style | |
| During business | Responsibility in advance, reasonable price list | |
| Warranty Service | human damage, two years warranty | |
| Sample Service | Provide samples, sample fee and courier fee paid by customers. The sample fee after the order returned. | |
One-Stop Solution Services:
Different Country has different climatic characters, We provide professional solutions on Doors & windows Profiles surface treatments and glazing to meet its diversity, it concerns the longevity of windows or doors and each function of energy-absorbing & saving.
AMGS also provide a one-stop solution service for your project, like the profiles Design, the wind resistance, waterproof, Soundproof, energy rating testing, Installation..
In addition, We Provide a one-stop service for shower screen, balustrade, pool fencing, etc other building materilas to save your labor, money and time.
Project:
