Basic Info.
Model NO.
automatic sliding door
Open Style
Sliding
Opening Type
Power Driven
Special Function
Sunscreen,Soundproof,Heat Insulation,Rustproof
Color
Customizable
Certification
ISO9001, CE, SGS
Position
Shopping Malls,Hotels, Banks, Cafes
Surface Finishing
Powder Coated, Fluorocarbon Coated
Glass
Tempered Glass
After-Sale Service
Online Technical Support
Engineering Solutions Capabilities
Graphic Design
Design Style
Modern
Hardware
Chinese Top Brand
Guarantee
Ship Within 7 Days After Confirming Payment
Transport Package
Protective Foam + Heat Shrinkable Plastic Film
Specification
Customizable
Trademark
YIWANX
Origin
Hefei, Anhui, China
HS Code
90328990
Production Capacity
10000 Units/Month
Packaging & Delivery
Package Size
80.00cm * 15.00cm * 250.00cm
Package Gross Weight
50.000kg
Lead Time
30 days (1 - 100 Square Meters)
To be negotiated ( > 100 Square Meters)
To be negotiated ( > 100 Square Meters)
Product Description
| Product | Aluminum profile automatic door |
| Material | Aluminum alloy, glass |
| Specifications | customized |
| Opening type | Automatic sliding |
| Features | waterproof/sunscreen/soundproof/rust-proof/firm |
| Aluminum profile | high-grade thermal insulation circuit breaker/abnormal aluminum profile |
| Surface treatment | powder Coated, fluorocarbon Coated, anodizing, electrophoresis, wood grain heat transfer |
| Aluminum color | black, white, gray, coffee, customized. |
| Aluminum thickness | 1.4mm, 1.6mm, 2.0mm, customized |
| Glass type | single-layer tempered glass, double-layer hollow tempered glass, frosted glass, laminated glass, low-E glass, radiation protection glass |
| Single glass | 6mm, 8mm, 10mm, 12mm |
| Double glass | 5mm+9A+5mm/5mm+12A+5mm/6mm+12A+6mm/ (glass can be 5mm/6mm) |
| Glass Color | Transparent |
| Hardware | OEM, ODM Chinese brand |
| Package | Protective foam + heat shrinkable plastic film/carton/wood packing or according to customer's special requirements |
| Delivery Time | 7-25 working days after receipt of deposit and withdrawal confirmation. |
YIWAN Automatic door have single leaf sliding door or bi-parting sliding door. it can be also applied to framed glass door.
The Application of Automatic Sliding Door :
*Retail and Food Stores
*Government Buildings
*Restored Sites
*Hotels
*Restaurants
*Office Buildings
*Hospitals & Other Health Care Facilities
*Schools
*Retirement Homes
*Independent Living Centers
*Facilities for the Disabled
*Airports
*Villas
Technical Data of Automatic Sliding Door | Gate sliding modes | Single-opening | Double-opening |
| Gate leaf weight | ≤1*155 kg | ≤2*145 kg |
| Gate leaf width | 600-1200mm | 500-1100mm |
| Opening speed | 150-600mm/s(Adjustable) | 150-550mm/s(Adjustable) |
| Closing speed | 120-550mm/s(Adjustable) | 120-500mm/s(Adjustable) |
| Motor | 24V 60/100W brushless DC motor | |
| Hold open time | 0-9second(Adjustable) | |
| Special Function | Security ,Hermetic | |
| Voltage | AC220V 50Hz-60Hz | |
| Operating Temperature | -20°C~60°C | |
R&D Team and Manufacturing
YIWAN has established special R&D department, Tooling department, Testing department, Assembling department, and Packing department. Meantime, in order to guarantee the quality of product, we purchase the imported high-quality machine from USA & Germany. The PCB of the controller are printed precisely by the SMT machine, the motor are coiled by the automatic coil winding machine. From the testing procedure, all the types of controllers and electronic parts will stay in power for more than 36 hours to check whether all electronic devices work well, each motor needs to pass the severe testing before selling, hardware will be checked under the strict QC system. So that our enterprise could supply products with good quality and competitive price.
Factory
Sales & Services
Hefei Yiwan Architectural Decoration Engineering Co., Ltd.takes Quality, Efficiency and Service as the motto. So we provide 24 months warranty. During the warranty period, we can replace the parts of problem with new ones for free.
YIWAN has established special R&D department, Tooling department, Testing department, Assembling department, and Packing department. Meantime, in order to guarantee the quality of product, we purchase the imported high-quality machine from USA & Germany. The PCB of the controller are printed precisely by the SMT machine, the motor are coiled by the automatic coil winding machine. From the testing procedure, all the types of controllers and electronic parts will stay in power for more than 36 hours to check whether all electronic devices work well, each motor needs to pass the severe testing before selling, hardware will be checked under the strict QC system. So that our enterprise could supply products with good quality and competitive price.
Factory
Sales & Services
Hefei Yiwan Architectural Decoration Engineering Co., Ltd.takes Quality, Efficiency and Service as the motto. So we provide 24 months warranty. During the warranty period, we can replace the parts of problem with new ones for free.
YIWAN have the most dedicated international service team. If you have any question or meet any problem, please feel free to contact us at any time, we'll reply you and help to solve the problem at the soonest.
OEM&ODM Service
We have professional design team, which can rebrand the customer's logo and company name as per customer's wishes.
YIWAN will never stop the pursuit of innovation with style. YIWAN would develop more innovative and market-oriented products in the future.
| YIWAN Competitive Advantages | |
| 1. | We are direct manufacturer & we have professional self design team, which is capable of satisfying customers' most demanding needs |
| 2. | Our products have World Class Quality Testing. We have certificates of SGS,CE, ISO9001. |
| 3. | We use high quality carton box,damp-proof & breakage-proof bubble wrap, as well as wooden case packing to keep the goods intact even in long-distance sea transportation. |
| 4. | Our special INSPECTION & QC department maintains a strict level of quality control. It ensures that all products are in compliance with specification. All goods and raw materials bought into the company go through strict inspection to ensure they are of good quality and correct. |
| 5. | We have large production capability and sufficient safety stock to ensure quick lead-time. |
| 6. | We are constantly innovating to launch new products every year. |
| 7. | We provide 24-month warranty for all of our products. |
