Basic Info.
Product Description
Structure:
| 1.Rails | 2.Track fixed Angle plate | 3. Horizontal rail | 4.Horizontal rail fixed Angle plate |
| 5 .Sealing strip | 6. Door shaft | 7. Coupling | 8. Seat |
| 9.Drum | 10. Spring | 11.Spring anti-fracture device. | 12.Fixed spring device (SBR) |
| 13.Fixed spring device (WS) | 14Industrial door opener | 15. Door opener control box | 16. Buffer |
| 21.Middle door panel | 22. Hinges | 19.Top door panel | 20.Lighting window (optional) |
| 25. Bottom sealing groove. | 26. Bottom seal and safety bottom | 27. Bottom pulley | 28.4 mm Steel rope |
| 29. Steel rope anti-fracture device. | 30. Bottom sealing strip | 31.Central sealing strip | 33.Top sealing strip |
| 35.Top seal groove | 36. Remote receiving device (optional) |
| Product name | Industry Sectional Sliding Door |
| Material | Galvanized steel with PU foaming inside |
| Material Construction | Steel-foam-steel, sandwich panel |
| Thickness of the steel plate | 0.376 - 0.476mm both available |
| Thickness of the panel | 40mm or 50mm |
| Section Style | Non-finger protection |
| Finger protection | |
| Section Size Range | 400mm-500mm in height, |
| Max 12000mm in width | |
| Section Surface Finish | Wood grain, orange peel, flush |
| Front-side design | Wood grain, with Rectangle/stripes design |
| Backside design | Wood grain, with Stripe design |
| Accessories | Single Track with min headroom for 350mm; |
| Double Track with min headroom for 150mm | |
| Door Openers | AC220V or 110V; DC Motor; 800-1500N |
| Opening Way | Electrical control and Manual operation |
| Color | light gray, coffee color and stainless steel color and other colors can be customized |
Why Choose Us?
Customers satisfaction is our eternal goal. We adhere to the management principles of "quality first, customer first and credit-based" since the establishment of the company and always do our best to satisfy potential needs of our customers. Our company is sincerely willing to cooperate with enterprises from all over the world in order to realize a win-win situation since the trend of economic globalization has developed with anirresistible force
Over the years, our company has been working with the well-known manufacturers work closely with gated, has introduced the latest and most sophisticated production equipment of various volumes gate. The use of superior Quality raw materials and high-quality components, and adhere to the " excellence, precision production" product concept, to ensure the production of a variety of beautiful rolling door products Generous, easy operation, security, security, durability, quality assurance. We spirit of "honesty, quality first, customer first, service leader," the case Purpose, passion for the community to provide the safest customers the best a variety of roll gates, but also provide comprehensive maintenance service.
